Please review the product documentation, or contact us for the latest information. Please note: All product design activities should refer to product drawings.
| Product Type Features |
-
Connector Shape : Circular
-
Mixed & Hybrid Connector : No
-
Connector & Housing Type : Receptacle
-
Connector System : Wire-to-Panel
-
Sealable : Yes
-
Primary Locking Feature : Contact Retainer
-
Connector & Contact Terminates To : Wire & Cable
|
| Configuration Features |
-
Connector Seal Code : T Seal
-
Connector Modification : Threaded Adapter
-
Blank Cavity Position : 0
-
Number of Positions : 31
|
| Contact Features |
-
Contact Type : Socket
-
Contact Size : Size 16
-
Mating Pin Diameter : 1.6 mm [ .062 in ]
-
Contact Current Rating (Max) (A): 13
|
| Operation/Application |
-
Circuit Application : Power
|
| Mechanical Attachment |
-
Mating Alignment : With
-
Mating Alignment Type : Guide Post
-
Terminal Position Assurance : No
-
Strain Relief : Without
-
Connector Mounting Type : Panel Mount
|
| Usage Conditions |
-
Operating Temperature (Max) : 125 °C [ 257 °F ]
-
Operating Temperature Range : -55 – 125 °C [ -67 – 257 °F ]
|
| Electrical Characteristics |
-
Operating Voltage (VDC): 250
-
Operating Voltage (VAC): 250
|
| Other |
-
Serviceable : Yes
-
Connector Position Assurance Capable : No
-
EU RoHS Compliance : Compliant
-
EU ELV Compliance : Compliant
|
| Body Features |
|
| Housing Features |
-
Housing Material : Aluminum Alloy
|
| Dimensions |
-
Connector Height : 68.5 mm [ 2.7 in ]
-
Product Length : 50.8 mm [ 2 in ]
-
Product Width : 47.6 mm [ 1.87 in ]
-
Compatible Insulation Diameter Range : 1.4 – 3.8 mm [ .055 – .15 in ]
|
| Industry Standards |
-
Operating Voltage (VDC): 250
-
Operating Voltage (VAC): 250
|
| Packaging Features |
-
Packaging Method : Package
-
Packaging Quantity : 1
|
If you need CAD or other information about the product, please contact us. Only part of the information is displayed on the website.
